The Complete Guide to Mold Making with SOLIDWORKS 2020

The Complete Guide to Mold Making with SOLIDWORKS 2020 is a quick paced book written to provide experienced SOLIDWORKS users with in-depth knowledge of the mold tools provided by SOLIDWORKS. Throughout this book you will learn the procedures necessary for using these tools to create and analyze effective mold designs. Utilizing step-by-step instructions, each chapter of this book will guide you through different tasks, from designing or repairing a mold, to developing complex parting lines; from making a core in the part mode to advancing through more complex tasks in the assembly mode. Throughout this book you will be introduced to using surfacing tools to repair models and prepare them for the mold making process. Towards the end of this book, you will learn how to work with SOLIDWORKS Plastics and Flow Simulation to simulate the way melted plastics flow during the injection molding process. You will also learn to analyze the thick-thin wall regions to predict defects on plastic parts and molds. Learning how to analyze plastic parts for errors and correct them early in the design stage is a valuable skill, which can save a significant amount of time throughout the span of the entire design process. Every project in this book is based on real world products. Each of these projects have been broken down and developed into simple, comprehensible steps. Furthermore, every mold design is explained very clearly in short chapters, ranging from 15 to 25 pages. Each step comes with the exact screen shot to help you understand the main concept of the design. Learn the mold designs at your own pace, as you progress from simple core and cavity creation to more complex mold design challenges.
